1. High-Performance 6W RGB Laser Output Equipped with imported semiconductor diodes delivering 6W total power (1500mW red/638nm, 1500mW green/520nm, 3000mW blue/455nm), featuring a narrow beam divergence of <1.3mrad for bright, sharp projections.
2. Multi-Control Connectivity & High-Speed Scanning Supports ILDA, DMX512, sound activation, auto mode, RJ45, and SD card control. Utilizes a 35kpps high-speed scanning system with 100kHz analog modulation for smooth, complex animations.
3. Advanced Hybrid Cooling & Robust Design Incorporates air cooling and TEC (thermoelectric cooling) technology within a durable aluminum casing. Operates reliably across -10°C to 45°C with 148W power consumption and global voltage compatibility (AC100-240V).
OPTICS
6W RGB Laser
Working temperature: -10C°-45C°
CONTROL
Control mode: Control mode: ILDA, DMX512, SOUND (sound control),AUTO (self-propelled), RJ45
Modulation mode: analog modulation 100Khz
Scanning system:35kpps ±30°
POWER CONSUMPTION
Voltage: AC110V-240V 50/60Hz
Laser power/wavelength: R (red):1500mW 638nm
G (green): 1500mW 520nm
B (blue): 3000mW 455nm
Full power: Power tested after passing the galvanometer
Divergence angle: ca.5mm/＜1.3mrad
PHYSICAL
Casing material: aluminum
Cooling method: air cooling
Size:235(L)*265(w)*190(H)mm
N.W.: 9KG
