1. High-Power 10W RGB Laser Output Combines high-performance red (3000mW/638nm), green (3000mW/520nm), and blue (4000mW/455nm) lasers for a total 10W output, delivering intense and vibrant projections with exceptional beam precision (<1.1mrad divergence).
2. Multi-Protocol Control & High-Speed Performance Supports ILDA, DMX512, sound activation, auto mode, and RJ45 connectivity. Features a 35kpps high-speed scanning system with 100kHz analog modulation for seamless, flicker-free animations and precise beam control.
3. Advanced Thermal Management & Robust Build Utilizes hybrid air cooling and TEC technology in a durable aluminum housing. Operates reliably across -10°C to 45°C with 148W power consumption and global voltage compatibility (AC100-240V).
OPTICS
10W RGB Laser
Working temperature: -10C°-45C°
CONTROL
Control mode: Control mode: ILDA, DMX512, SOUND (sound control),AUTO (self-propelled), RJ45
Modulation mode: analog modulation 100Khz
Scanning system:35kpps ±30°
POWER CONSUMPTION
Voltage: AC110V-240V 50/60Hz
Laser power/wavelength: R (red): 3000mW 638nm
G (green): 3000mW 520nm
B (blue): 4000mW 455nm
Full power: Test power after passing through the galvanometer
Divergence angle: ca.5mm/＜1.1mrad
PHYSICAL
Casing material: aluminum
Cooling method: air cooling+ TEC cooling
Size:265(L)*230(w)*190(H)mm
N.W.: 9.2KG
